1A1 resin diamond grinding wheel for cylinderical grinder

Jig grinding is different from cylindrical and surface preci…

Moresuperhard double disk grinding wheel has successed matched: Lapmaster DDG-45 using 457mm double disk grinding wheel, DDG-600 using 600mm double disk grinding wheel and Speedfam DSM 9B-5L-IV using638mm double disk grinding wheel, and double disk grinding wheel(1000D*350H*58T) for SKF-PM1000 grinding machine.

Flute grinding is a precison operation,  high stock removal– a cutting depth of 7-8 mm is not unusual. The large contact area makes it difficult for the coolant to reach the grinding zone, thus, excessive heat is generated which could cause damage to the work piece surface and/or reduce the particle strength of the heat-sensitive diamond grits.

Carbon fiber is mainly composed of carbon element, with high temperature resistance, friction resistance, thermal conductivity and corrosion resistance characteristics of fiber shape, soft, can be processed into a variety of fabrics, because its graphite microcrystal structure along the fiber axis preferred orientation, so along the fiber axis direction has a high strength and modulus. The density of carbon fiber is small, so the specific strength and modulus are high.

Vitrified CBN grinding head is the ideal tool for gear inner hole processing. The corundum grinding wheel (grinding head) is used to grind the inner hole of the gear. However, due to the high surface hardness of the gear after carburizing, the corundum grinding wheel has poor shape retention during the grinding process, and the shape needs to dressing frequently to ensure normal operation.

The diamond mounted points is mainly made of diamond abrasive. Therefore, the purpose of the diamond grinding head is quite special. It is indispensable for grinding the inner hole and other places that the grinding wheel cannot grind. It is mainly used for grinding, polishing and grinding. At the same time, according to the above characteristics of diamond, it can be divided into the use of grinding high and hard alloy and non-metallic materials according to the material.

Case of 14EE1 resin diamond grinding wheel for nitinol endodontic file
